Stage Mechanical Equipment

Stage Mechanical Equipment for Theaters and Performance Venues

Our stage mechanical equipment covers vertical lifting, 360° rotation, horizontal stage extension, stage hoisting, and scenery movement. From individual stage hoists to integrated lifting and rotating platforms, we provide stage mechanical equipment and custom stage machinery solutions for theaters, auditoriums, performing arts centers, and other professional venues.




  • car turntable
    The Turntable wagon is a dedicated rotating device specifically designed for car exhibitions. Its core function is to enable a 360° full-round rotation display of the vehicle, allowing for a...
    read more
  • Telescopic Stage
    The run out extension platform is a professional mechanical equipment for horizontally extending the stage. It can extend linearly along the front or side edge of the main stage, enabling...
    read more
  • Lifting and Rotating Stage
    The lifting and rotating stage is a professional mechanical equipment installed beneath the stage. It integrates the functions of vertical lifting and 360° rotation, and is used for actors'...
    read more
  • Stage Wagon System
    The stage wagon system is a professional mechanical equipment for core horizontal movement under the stage. It moves horizontally back and forth along the preset track, used for rapid scene...
    read more
  • Theater Seating
    Our theater seating combines comfort, durability, and elegant design for theaters, auditoriums, cinemas, and performance venues. Ergonomic backrests, high-quality upholstery, and strong structural...
    read more
  • Pop-up Toaster Lift
    The Pop-up toaster lift is a professional mechanical device for rapid lifting on the stage floor. It achieves the instant lifting and appearance of actors/dragons through short stroke, high...
    read more
  • Single Point Hoist Stage
    Model: HBDD-250~800
    Load: 2.5~8KN
    Distance: ≤30m
    Speed: ≤1.8m/s
    Applicable wire rope diameter: 6~14 mm
    read more
  • Multi layer Winding Stage Hoist
    Model: HBDS-250-600
    Load: 2.5~6KN
    Distance: ≤10m
    Speed: ≤0.3m/s
    Applicable wire rope diameter: 5.1mm
    read more
  • Self Winding Stage Hoist
    Model: HBZPS-250~2000
    Load: 2.5~20KN
    Distance: ≤30m
    Speed: ≤1.8m/s
    Application wire rope diameter: 4.2~12mm
    read more
  • Double Point Stage Hoist
    Model: HBSD-250~800
    Load: 2.5~8KN
    Distance: ≤40m
    Speed: ≤1.8m/s
    Applicable wire rope dimeter: 5.1~12mm
    read more
  • Stage Curtain Truss
    A stage curtain truss is a truss structure system specifically designed to suspend, support, or secure stage curtains, and serves as a fundamental component of the framework in professional stage...
    read more
  • Rigid Fire Curtain
    Structure: Rigid (steel + sheet metal)
    Can this be collapsed: NO
    Stability: High
    Appearance: Decorative
    Applicable locations: Fixed partition
    read more
First 123 Last


Stage Mechanical Equipment for Different Movement Requirements

Our product range includes:

  • Lifting and Rotating Stage: Combines vertical lifting with 360° forward and reverse rotation. The two movements can operate independently or simultaneously.
  • Telescopic Stage: Extends the usable stage area horizontally along the front or side of the main stage.
  • Stage Wagon System: Moves stage structures horizontally along preset tracks for scene changes and stage layout adjustments.
  • Stage Hoist: Provides mechanical lifting for stage equipment and suspended components.
  • Orchestra Pit Lift: Provides vertical movement for the orchestra pit platform at the front of a theater stage.
  • Stage Lighting Bridge: Provides a fixed truss structure for equipment installation and personnel operation.
  • Performer Flying System: Combines tracks, trolleys, traction equipment, and suspension components for performer movement.

Stage Hoist Specifications

Our Self Winding Stage Hoist is available in the HBZPS-250~2000 model series.

Parameter Specification
Model HBZPS-250~2000
Load 2.5–20 kN
Distance ≤30 m
Speed ≤1.8 m/s
Applicable wire rope diameter 4.2–12 mm

These specifications provide a starting point for matching the hoist to the required load, lifting distance, speed, and wire rope configuration.

Lifting and Rotating Stage Configuration

The Lifting and Rotating Stage combines two movements in one mechanical system installed beneath the stage. It supports vertical lifting and 360° rotation for performer entrances, prop movement, and scene transitions.

The lifting and rotating functions can operate independently or in synchronized mode. Forward and reverse rotation, variable-frequency stepless speed control, and preset-height or preset-angle positioning can be configured according to the control system.

Configuration Item Available Options
Platform shape Circular, square, or special-shaped
Drive system Electric servo or hydraulic
Lifting stroke Customized according to project requirements
Rated load Customized according to project requirements
Rotation speed Customized according to project requirements
Platform surface Anti-slip surface and customized finish
Appearance Customized decorative finish and enclosure
Safety protection Travel limiting, fall prevention, overload protection, emergency stop, and power-loss protection
Control integration Connection with the main stage control system, subject to technical evaluation

The supporting steel structure is designed according to the specified load and installation conditions. Final equipment configuration is determined by the stage layout, available installation space, movement requirements, and control interfaces.

Custom Stage Machinery Design and Project Integration

We develop stage machinery solutions according to project drawings and venue conditions. Customers can provide CAD drawings showing the stage opening width and depth, grid ceiling height, orchestra pit depth, and other relevant structural information.

Our engineering team can prepare customized equipment proposals, detailed design drawings, and electrical wiring diagrams. Equipment dimensions, mechanical configurations, drive options, and control arrangements are evaluated against the actual project requirements.

The control system specified in our company FAQ is PLC. For integrated stage systems, the control interface and coordinated operation requirements are reviewed as part of the equipment design.

Manufacturing, Inspection and Project Support

As a stage mechanical equipment manufacturer, our manufacturing base covers approximately 7,000 square meters and operates multiple specialized production lines. Our team includes approximately 20 engineering and management staff members across engineering, R&D, design, production, and project management.

Our manufacturing facilities include CNC machining centers and large industrial machining platforms for processing mechanical components and structural parts.

Before shipment, equipment undergoes simulated operating tests. The inspection process includes load testing, speed calibration, and noise monitoring. Factory Acceptance Testing (FAT) can also be arranged for large turntables and lifting platforms before shipment.

For project implementation, we provide:

  • Customized equipment proposals based on site drawings.
  • Detailed mechanical design and electrical wiring drawings.
  • Production progress updates with photos and videos.
  • 3D animated installation guidance.
  • Professional installation team support when required.
  • Follow-up service for equipment operation.

Request a Stage Mechanical Equipment Quotation

Send us your stage layout or CAD drawings together with the required equipment type, platform dimensions, rated load, lifting stroke, operating speed, and project quantity.

Our team will review the available information and prepare a suitable stage machinery configuration and quotation for your project.
