Custom Stage Flying Equipment for Theatres, Concerts and Live Shows
Our Performer Flying System is engineered for controlled aerial movement of performers in professional entertainment venues. Based on the performance design and venue conditions, the system can be configured for vertical lifting, synchronized multi-point movement, and coordinated 2D or 3D flying effects.
We provide project-specific mechanical equipment and control solutions, including flying winches, wire-rope routing components, position feedback and operator controls. The final configuration is developed around the required movement path, performer load, supporting structure and applicable project requirements.
Request a Project Proposal
Product Highlights
Custom movement paths, lifting heights and operating speeds
Single-point or coordinated multi-point configurations
Programmable acceleration, deceleration and positioning
Safety functions specified according to the project risk assessment
Mechanical and control integration for new or existing venues
Flying Effects and Applications
The system can support performer entrances and exits, aerial dance, concert flying effects, theatrical productions, television shows, theme park performances and opening ceremonies.
A basic configuration provides controlled vertical movement. More complex flying effects require additional axes, suitable wire-rope routing and coordinated control. 2D or 3D capability must be confirmed against the proposed system layout; it is not a feature of every single-point installation.
System Configuration
| Component | Function |
|---|---|
| Flying winch and drive | Provides controlled movement of the flying point |
| Wire rope, drum and guide pulleys | Transmits motion along the engineered rope path |
| Suspension and performer connection equipment | Connects the performer to the flying system according to the approved rigging design |
| Position feedback | Monitors movement and supports repeatable positioning |
| Control cabinet and operating console | Provides operation, programming and system monitoring |
| Braking and protective devices | Configured according to the system design and project requirements |
| Load monitoring and rope condition detection | Available where specified for the application |
The bill of materials is confirmed after reviewing the venue drawings and intended flying sequence.
Reference Technical Parameters
| Parameter | Available reference range or configuration |
|---|---|
| Rated load | 250–1,200 kg per hoist point* |
| Hoist points | Typically 1–2 points per system* |
| Lifting speed | Up to 1.8 m/s* |
| Travel distance | Up to 30 m* |
| Wire-rope diameter | Ø4.2–Ø12 mm* |
| Motor power | 1.5–22 kW* |
| Drive options | Motor and gearbox or servo drive |
| Position feedback | Encoder or absolute encoder |
| Control options | Manual, automatic or programmable |
| Power supply | AC 380 V, 50/60 Hz* |
*These figures come from the supplied product information and are reference values, not a single model's guaranteed specification. Rated load, speed, travel, rope selection and motor power must be confirmed together for each project. In particular, the permissible performer load depends on the complete engineered system and its operating conditions.
Safety and Project Engineering
Performer flying requires assessment of the entire installation, including the supporting structure, rigging path, dynamic loads, movement envelope, controls, operating procedures and rescue arrangements. Depending on the project, the system design can incorporate dual brakes, travel limits, emergency stops, position feedback, load monitoring and slack-rope detection.
What We Need for a Proposal
Please send us the following information so we can recommend a suitable configuration:
Venue drawings, stage dimensions and available support points
Number of performers and maximum load at each flying point
Required vertical and horizontal travel
Target speeds and the planned movement sequence
Number of flying points and whether synchronized movement is required
Installation location, power supply and control integration needs
Destination country and applicable project requirements
Send Your Flying Plan or Venue Drawings for a Custom Proposal
FAQ
Can the system be customized for our venue?
Yes. The equipment layout, travel, speed, rope routing and controls are specified after reviewing the venue and performance requirements.
Can it create 3D flying effects?
A coordinated multi-axis design can support 3D movement. Feasibility depends on the available structure, movement path and control configuration.
Are dual brakes and load monitoring included?
These functions should be identified in the project specification. Their inclusion and implementation are confirmed in the final technical proposal.
Can you integrate the system with existing stage automation?
Integration can be assessed after reviewing the existing control system, interfaces and operating requirements.
